System Overview
Supports up to 24 Antminers or 30 Whatsminers
Up to 120kW cooling capacity to gain overclocked hashrate
Single-loop circulation Integrates smart PDUs and networking Integrates circulation pumps and piping
Supports either dry cooler (by default) or closed water cooling tower
High density and space saving
Easy to deploy
Supports remote management
Optional
Optional power distribution cabinet
Optional CDU module for dual loops
Alternative closed-circuit water cooling tower
Specifications
| B24D Tank | |
| Outer size | 2486*746*530mm |
| Input voltage | 3-phase 350-480V 50/60Hz |
| Output voltage | Single-phase 200-277V 50/60Hz |
| Cooling capacity | 120kW@35°C |
| Operating temp | -10°C - 40°C |
| N.W | 172kg |
| Coolant volume | 750L |
| Inlet and outflow temperature | 45/65°C |
| Power load (max) | 120kW |
| Capacity | 24 Antminers or 30 Whatsminers |
| External cooling | Dry cooler/water cooling tower |
| Dry Cooler (EC Fan) | |
| Outer Size | 2186*1874*2100 |
| G.W. | 769kg |
| Input Voltage | 3-phase 350-480V 50/60Hz |
| Cooling Capacity | 120kW@35°C |
| Max Power Load | 4kW |
| Air Volume(m³/h） | 38299 |
| Noise | 65dB(A) (@25°C,16m) |
Note: About the transportation of liquid cooling equipment
For most areas, the liquid cooling equipment will be shipped to you via sea freight. Ports and receiving points in different regions will incur different shipping charges. It is recommended that you contact customer service to confirm address details and calculate shipping costs before placing an order.
